# Aptī Algoritmi

#### Vreda Pieterse

Aptī Algoritmi is the Latin for (fit / apt / suitable / fitting / prepared / useful) Algorithms.

This site hosts implementations of algorithms that are ready for use in software construction.

I am in the process of creating a topic map of algorithms that solve the transitive closure problem. The topic map is a classification of these algorithms and should ideally point to implementations of algorithms. As part of this endeavor, I implement the algorithms that I include in the topic map and publish them here to be accessible for the users of my topic map and others that may want to use these implementations. The aim of the topic map is ultimately to aid developers in finding suitable algorithms when constructing software.

### Binary Relation

A binary relation R on a set S is a collection of ordered pairs of elements of S. It can be represented in set notation as a set of pairs. It can be visualised as a directed graph where the vertices correspond with the elements of S and the edges correspond with the elements of R. It can also be represented using an adjacency matrix — i.e. a square matrix where the entry at (i,j) is 1 if (i,j) is in R, with other words, there is an edge from vertex i to vertex j in the graph representation of R; otherwise the entry is 0. The following figure shows these three representations of an example of a binary relation on the set S ={A, B, C, D}.

### Transitive Closure

The transitive closure of a binary relation R is an extension or superset of R such that whenever (i,j) and (j,k) are in the extension, (i,k) is also in the extension. The following figure shows the three representations of the transitive closure of the binary relation shown in the previous figure.

### C++ Implementations

Each of the following downloadable archives contains C++ source code of a command-line program consisting of the following three functions as well as a main function calling these functions:
`getRelation`
Read standard input and return a pointer to a variable of the appropriate data stucture for the algorithm.
`transitiveClosure`
Takes a pointer to a variable of the appropriate data structure containing the input relation as a parameter and transforms the value of this variable to the transitive closure of the input relation.
`showRelation`
Takes a pointer to a variable of the appropriate data structure containing a relation as a parameter and print this relation to standard output.

All these implementations use square boolean matrices to represent relations. To do this, a vector of elements is used where each of these elements represent a row in the matrix. Each algorithm has four implementations

1. A standard implementation named *Std that uses a `vector< char* >` to represent the relations. These implementations only need the standard template library.
2. A boosted implementation named *Boost that uses a `vector< dynamic_bitset<> >` to represent the relations. The `dynamic_bitset<>` is defined in the boost c++ libraries.
3. A standard implementation that applies short circuiting names Short*Std
4. A boosted implementation that applies short circuiting named Short*Boost

#### Coat Algorithms

Coat algorithms calculate the transitive closure of a relation by coating the given relation with additional edges until the transitive closure is reached. This is achieved through repeated multiplaction of the adjacency matrix of the relation.

The coat algorithms apply short circuiting by using row and column monitors. When a column or row used in a claculation is empty the calculation is skipped.

The Fused Coat Algorithm
An optimasation of Prosser's algorithm: A loop that multiplies two matrices and a loop that adds two matrices are fused.
FusedCoatStd.zip (1306 B 2014-11-15 08:14)
FusedCoatBoost.zip (1331 B 2013-12-19 20:11)
ShortFusedCoatStd.zip (1623 B 2014-11-15 09:38)
ShortFusedCoatBoost.zip (1643 B 2015-01-08 14:06)
The Monitored Coat Algorithm
Apply repeated marix multiplication and uses a change monitor to know when to stop.
MonCoatStd.zip (1377 B 2013-12-19 20:27)
MonCoatBoost.zip (1433 B 2013-12-19 20:12)
ShortMonCoatStd.zip (1663 B 2015-01-08 08:03)
ShortMonCoatBoost.zip (1693 B 2015-01-08 14:07)
The Neat Coat Algorithm
An optimasation of the monitored coat algorithm: A loop that multiplies two matrices and a loop that adds two matrices are fused.
NeatCoatStd.zip (1379 B 2013-12-31 12:11)
NeatCoatBoost.zip (1420 B 2013-12-31 12:28)
ShortNeatCoatStd.zip (1687 B 2015-01-08 08:03)
ShortNeatCoatBoost.zip (1726 B 2015-01-08 14:07)
Prosser's Algorithm5
Apply repeated marix multiplication and stop after n - 2 iterations.
ProsserStd.zip (1308 B 2013-12-08 16:08)
ProsserBoost.zip (1299 B 2013-09-02 02:42)
ShortProsserStd.zip (1603 B 2015-01-08 08:04)
ShortProsserBoost.zip (1407 B 2015-01-08 14:07)

#### Grow Algorithms

Grow algorithms calculate the transitive closure using the recursive definition of transitive closure. This is achieved by adding rows in the adjacency matrix.

The grow algorithms apply short circuiting by using a row monitor. When a row used in a calculation is empty or full row additions are short circuited or speeded up.

Baker's Algorithm3
Iterates through the entries in the marix in row order and uses a change monitor to know when to stop.
BakerStd.zip (1025 B 2013-12-08 16:07)
BakerBoost.zip (993 B 2013-09-01 18:08)
ShortBakerStd.zip (1213 B 2015-01-08 08:01)
ShortBakerBoost.zip (1267 B 2015-01-08 14:05)
The Blocked Column Algorithm1, 2
A variation of Warshall's algorithm: Columns are processed in blocks while applying loop tiling to minimise cache thrashing. The elements within the block and within the square section around the diagonal are processed in column order. After processing the elements in the square section, the rest of the elements within a block are processed in row order
BlockColStd.zip (1303 B 2014-04-21 17:14)
BlockColBoost.zip (1458 B 2014-04-21 17:05)
ShortBlockColStd.zip (1668 B 2015-01-08 08:01)
ShortBlockColBoost.zip (1800 B 2015-01-08 14:05)
The Blocked Row Algorithm1, 2
A variation of Warren's algorithm: Rows are processed in blocks while applying loop tiling to minimise cache thrashing. The elements within a block are processed in column order
BlockRowStd.zip (1256 B 2014-01-26 15:59)
BlockRowBoost.zip (1331 B 2014-01-26 15:54)
ShortBlockRowStd.zip (1581 B 2014-10-22 12:50)
ShortBlockRowBoost.zip (1615 B 2015-01-08 14:05)
Martynyuk's Algorithm4
Iterates through the entries in the marix in row order and stop after log2n iterations.
MartynyukStd.zip (1028 B 2013-12-08 16:07)
MartynyukBoost.zip (1004 B 2013-09-02 20:10)
ShortMartynyukStd.zip (1236 B 2015-01-08 08:02)
ShortMartynyukBoost.zip (1263 B 2015-01-08 14:06)
Warren's Algorithm6
Iterates through the entries in the marix in row order. Process entries below the main diagonal in the first pass and those above in the second pass. It calculates the transitive closure in two passes.
WarrenStd.zip (2014 B 2014-01-08 19:02)
WarrenBoost.zip (970 B 2014-01-08 19:22)
ShortWarrenStd.zip (1260 B 2015-01-08 08:04)
ShortWarrenBoost.zip (1227 B 2015-01-08 14:08)
Warshall's Algorithm7
Iterates through the entries in the marix in column order. It calculates the transitive closure in one pass.
WarshallStd.zip (988 B 2013-12-08 16:08)
WarshallBoost.zip (931 B 2013-09-02 17:41)
ShortWarshallStd.zip (1256 B 2014-10-12 17:56)
ShortWarshallBoost.zip (1201 B 2015-01-08 14:08)

### Usage

Compile and run the code using any C++ compiler for example the C++ compiler that can be found in the GNU Compiler Collection on Linux, the C++ compiler that is part of Minimalist GNU for Windows, or the C++ compiler that is included in the Command Line Tools for Xcode on a Mac.

When using the code that relies on boost c++ libraries, the dynamic bitset library needs to be installed on your machine. When issuing the compile command, the boost directory has to be in the search path of your C++ compiler. Assume, for example, that you installed `boost_1_54_0.bz2` in the `/usr/local/boost` directory, you can compile `BakerBoost.cpp` by issuing the following command in the directory where `BakerBoost.cpp` is saved:

`g++ -I /usr/local/boost/boost_1_54_0/boost BakerBoost.cpp`

If `BakerBoost.cpp` is compiled using the above mentioned command, a compiled version of this program is saved in the current directory. On Windows it is called `a.exe` and on Linux and Unix (Mac), it is called `a.out`. It can now be executed by typing `a` in Windows or `./a.out` in Linux/Unix.

It should not be too difficult to adapt the code and reuse it in any project that needs it.

If you experience any problems when using the code, feel free to drop me an e-mail. I cannot guarentee that I will be able to assist, but might be able to give guidance in solving your problems. Your queries will help me to compile a troubleshooting guide.

#### Test data

`InputData.zip` is an archive containing some input files. Each file contains input to the provided programs to specify the adjacency matrix of a randomly generated relation. It's filename encodes facts about this relation. The first character is an alphabetical character which is varied to have more than one relation having the same characteristics. The next four characters is a four digit number specifying the dimension of the relation. The last two digits is the percentage filled. Thus, `C0600_05.txt` is input containing the adjacency matrix of a 600 × 600 relation that has 95% zeros and 5% ones.

These are text files that can be piped as input to a compiled version of each of the downloadable programs. The following is the command to execute an executable with C0600_05.txt as its input on Windows, when assuming the executable is called `a.exe`:

`a < C0600_05.txt`

Similarly on Linux/Unix, assuming that the executable is called `a.out`, the command is:

`./a.out < C0600_05.txt`

This archive also contains the source code of a program called `generate.cpp` which you can compile and run to generate more data.

#### Test Run

Each of the the programs offered here is a command-line program to calculate the transitive closure of the relation that is entered using standard input. The input required is an ASCII stream of 0's and 1's representing the adjacency matrix of a binary relation preceded by an integer value specifying the width of this matrix. All the programs use the same input format and produce the same output. The following is a test run of a compiled version of one of these programs. This test run calculates the transitive closure of the relation shown in the above mentioned example.

 Type the dimension, a comma, and then a continous stream representing the adjacency matrix of the relation: 4,0100001010010000 Input Relation: 0100 0010 1001 0000 Transitive Closure of the Relation: 1111 1111 1111 0000

### Other Implementations

A really cool implementation of a transitive closure algorithm implemented by Vladimir Prus is provided in the graph library that is included in the boost c++ libraries. Information about this algorithm can be found at transitve closure documentation at boost.
